Stacking Studs (Stud Extenders)

These Stacking Studs are typically used to extend the length of your weld stud. Also know as Stud Extenders. Can be used with any threaded fasteners.

The typical length is 1″ but can be made in other sizes upon request.

Material: Low carbon steel, stainless steel, aluminum

Available in 1/4-20 & 3/8-16 extender

SKU: sext Category:

Description

Stacking Studs

Stacking Studs (also known as stud extenders and shoulder studs) are your solution when additional fastener length is required. These unique studs are not stud welded. Instead, they are installed onto pre-existing studs by hand. Our Stacking Studs are composed of low-carbon steel, stainless steel, and aluminum.

Material

Low carbon steel, stainless steel, and also aluminum

Available

  • 1/4-20 thread
  • 3/8-16 thread

Arc Stud Welding

Arc stud welding is a process by which an operator welds a metal fastener to a parent metal through a fusion weld. Using a “ferrule” to capture and retain the weld’s heat. This process creates a molten metal at the weld site. Metal then cools and produces a weld that is stronger than the stud itself. Drawn arc stud welding can weld dissimilar metals such as mild and stainless steel, as well as aluminum.

Stacking Studs/Stud Extenders are a special form of stud that is attached by hand to pre-existing arc studs.

Have Questions?

For more information on this product, call our office at 800-252-1919 or email us at Info@studweldprod.com and we will get back to you shortly!

Not What You’re Looking For?

To view our full selection of capacitor discharge studs and arc studs, click here. Click here to view our selection of arc stud welders.
