Nito Kohki WA-5000 Automatic Drill (2″x 3″ Hole Capacity)


Nitto Kohki WA-5000 Quick Facts:

Model WA-5000
Power Source (single phase) 110-120 V AC 50/60Hz
Rated Power Consumption 1,150 w
Rated Current 10.8 A
No Load Speed 350/650 rpm
Magnet Power Consumption 75 w
Hole Diameter Capacity 2″ Max
Depth of Cut Capacity 3″ Max
Magnet Holding Power 2,200 lbs
Magnet Dimensions 4″ x 8″
Weight 51 lbs
Included Accessories
  • UEA0835-0 pilot pin 5/16″ x 2 ” DOC
  • 3 mm & 4 mm allen wrench
  • 8 mm x 10 mm combination spanner
  • chip guard assembly
  • motor side handle
  • sample cutting fluid
  • safety chain
  • molded plastic carrying case

WA 5000 Spec Sheet

SKU: WA 5000 Category:


The Nitto Kohki WA-5000 Automatic Drill offers power and efficiency without the loss of safety or mobility!

The WA-5000’s features at a glance:

  • Capacity: 2″ x 3″ maximum hole drilling capacity!
  • Versatile: Accepts both Jetbroach carbide tipped cutters and Hilbroach HSS annular cutters!
  • Simple: Novel one-touch arbor system means installing and removing cutters requires no extra tools!
  • Durable: Precision-machined die cast aluminum frame protects the interior motor from damage.
  • Safety: Overload stop detection system prevents motor and cutter damage, increasing the lifespans of your equipment!

This Nitto Kohki Automatic Drill also includes a load sensor system to ensure the proper speed for optimum cutting conditions!

Stud Welding Products offers a 1-year limited warranty on all Nitto Kohki Drills! Each purchase includes a convenient carrying case and sample cutting fluid. Click here to see Nitto Kohki WA-series drills in action!

Not What You’re Looking For?

See our full line of Nitto Kohki Automatic Drilling Machines here and click here to view a short blog on the benefits of automatic drills! For our cutters, click here.


If you have any questions about this product or others, email us at or call our office at 800-252-1919 and we will get back to you as soon as we can!
